LP 280 Nitrox Generator

Price on request

Nuvair has designed the Nuvair Low Pressure Nitrox Generators for installations in facilities that all ready own a High Pressure Compressor and are ready to produce Nitrox. These packages are clean enclosed, easy to operate, turnkey Nitrox generators.

Turn key, hassle free air / Nirtrox.

Features

• Nuvair Nitrox Membrane System with (2) O2 Analyzers
• Automatic Shut Down for High Pressure and Temperature
• Automatic Condensate Drains
• Refrigerated Air Dryer for Long Filter Life
• Hankison LP Filtration for Membrane System
• Microprocessor Control or Manual Control for Managing Pressure, Temperature & Maintenance

Advantages

• Simplest, Most Cost Effective Nitrox System Available
• Supply LP Nitrox Containing 21 – 40% Oxygen
• None of the Costs, Hassles, or Hazards of O2 Blending
• Systems to Fit Most HP Compressors
• Rotary Screw LP Compressor Provides Quiet Operation & Low Maintenance

Specifications

LP 280 Nitrox Generator

Physical Specifications

• Height: 48 in (122 cm)
• Width: 59 in (150 cm)
• Depth: 30 in (76 cm)
• Weight Horse Power: 635 lbs (288 kg) 10 hp (7.5 kW)

Full Load Amps

• 440V / E3 / 50 – 60 Hz: 16 A
• 380V / E3 / 50 Hz: 19A
• 230V / E3 / 50 – 60 Hz: 30A

LP Compressor

• Capacity @ 175 psi: 30 cfm (850 L/min)

Membrane Input

• Operating Pressure: 90 – 175 psi (6 – 12 bar)
• Supply Air Volume: 8 – 30 SCFM (212 – 850 L/min)
• Optimum Temperature: 110 +/- 5° F (43 +/- 3° C)

Rated to Supply

• FAD for 40% Oxygen: 10 CFM (280 L/min)
• FAD for 36% Oxygen: 12.5 CFM (350 L/min)
• FAD for 32% Oxygen: 17 CFM (480 L/min)
